21
Environmental ratings
Operating temperature: 32˚F (0°C) to 140˚F (60˚C)
Storage temperature: -13°F (-25°C) to 185°F (85°C)
Humidity: Up to 85% RH, non condensing
Level of waterproofing: IPx5 for TUV (CE/AUS/NZS) & CSA Enclosure #2
Mechanical
in.yj
Weight: 3.1 lb (1.41 kg)
Dimensions (W x H x D): 12.08" x 7.38" x 3.74" (307 x 187 x 95 mm)
heat.wav
Weight: 4.65 lb (2.1 kg)
Dimensions (W x H x D): 19.58" x 4.94" x 3.92" (497 x 125 x 100 mm)
in.yj UL/CSA electrical specifications*
1
Input rating (in.yj-3) : 120/240 V nominal (+5/-10 %)
60 Hz, (2 lines required with neutral) 40 A max.
Input rating (in.yj-2) : 120/240 V nominal (+5/-10 %)
60 Hz, (2 lines required with neutral) 32 A max.
or : 120 V nominal only (+5/-10%) , (single line with neutral) 16 A Max
Heat.wav rating :
Voltage : 120 V or 240 V, 1 kW at 120 V
Wattage : 4 kW at 240 V, 1 kW at 120 V
Flow rate : Minimum of 18 GPM (68,1 LPM) is required
Device*
2
Voltage*
3
Maximum current
Pump 1 (2-spd) 120 or 240 V 15 FLA/60 LRA (inrush)
Pump 2 (1-spd)*
4
120 or 240V 15 FLA/60 LRA (inrush)
O3*
5
120 or 240 V 3 FLA/6 A
Direct out 1 120 or 240 V 5 A (always on)
Light output 12 Vdc 0,5 AMP (6W Light bulb)
UL/CSA Standards
UL 1563 Sixth Ed. (2012)
UL File: E182156
CSA No. 22.2 - 218.1-M89. (2013)
*
1
Certain current limits may apply. Please talk to your customer service representative for more information.
*
2
Total of Pump 1, O3 and Direct out should not exceed 16 A for UL/CSA version.
*
3
The output voltage is selectable only if input supply voltage is 120/240 V.
*
4
Only available on in.yj-3.
*
5
The ozonator is connected in parallel with the Pump 1 low speed, therefore they cannot be controlled independently.
Specifications
Model
in.yj-2: 2 outputs
in.yj-3: 3 outputs
