Geeetech Rostock 301 Building Instruction

www.geeetech.com
Page 23
ShenZhen GETECH CO.,LTD
M3 x 16 Screw
#21
3
Square nut
#13
3
M3 washer
#5
9
M2.5 nut
#8
6
Upgraded item: The holes design of the extruder is upgraded to fit different model of
Rostock type 3d printers, such as the single extruder, the dual extruder and this 3
extruder model.
Step 1. Mount the three endstops (#47) onto the endstop mounts (#A6) in the same
direction. Fix in place with M2.5 x 16 screws (#17) and M2.5 nut (#8)
ensuring that they are tightly fixed.
