Geeetech Rostock 301 Building Instruction

www.geeetech.com
Page 22
ShenZhen GETECH CO.,LTD
Step 1. Mount the drive wheel mount to the top plate (#A5) on A1; screw them up
with M3 x 25 screws (#23) , M3 nut (#9) and washers (#5).
Repeat the procedure for the other two drive wheel mounts.
Videos
2.2 Endstop mount
Name
Part #
Qty.
Top plate
#A1
1
Endstop mount
#A6
3
Endstop
#47
3
M2.5 x 16 screw
#17
6
