Geeetech Rostock 301 Building Instruction

www.geeetech.com
Page 38
ShenZhen GETECH CO.,LTD
M4 x 8 Screw
#25
6
M8 Washers
#7
6
M4 washer
#6
6
Step 1. Slide a M8 washer (#7) on to an end of the smooth rod (#1). Insert that
end of the rod (#1) into one of the holes located on the tower of base plate
(#A1).
Step 2. Fix the rod (#1) in place with M4 washer (#6) and M4x8 screw (#25).
