12 ADV200 • Functions description and parameters list

Menu PAR Description UM Type FB BIT Def Min Max Acc Mod

1.26 1400DigitaloutputXmon UINT16 0 0 0 R FVS

The status of the digital outputs of the expansion card is displayed. It can also be read via a serial line or

eldbus. The data are contained in a word, where each bit is 1 if voltage is supplied to the corresponding input

terminal.

1 Output enabled.

0 Output disabled.

I.e. :

000000000011

Active DO

Active DO 2

Menu PAR Description UM Type FB BIT Def Min Max Acc Mod

1.27 5400Diginp0Extmon UINT16 32 0 0 4294967295 ER FVS

This parameter displays the state of external inputs from 0 to 31.

Menu PAR Description UM Type FB BIT Def Min Max Acc Mod

1.28 5402Diginp1Extmon UINT16 0 0 4294967295 ER FVS

This parameter displays the state of external inputs from 32 to 63.

Menu PAR Description UM Type FB BIT Def Min Max Acc Mod

1.29 5450Digitalout0Extmon UINT16 0 0 0 R FVS

This parameter is used to read the state of external outputs from 0 to 31.

Menu PAR Description UM Type FB BIT Def Min Max Acc Mod

1.30 5452Digitalout1Extmon UINT16 0 0 0 R FVS

This parameter is used to read the state of external outputs from 32 to 63.

gefran ADV200 Functions Description And Parameters List
