ADV200 Functions description and parameters list 11
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.09 3260Bresoverloadaccum perc UINT16 16/32 0 0 100 ER FVS
The braking resistor overload limit is displayed (100% = alarm threshold).
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.20 1066Enablestatemon BIT 16 0 0 1 R FVS
The drive Enable command status is displayed. Voltage must be present on terminal 7. The FR Forwardstart
command is needed to start the inverter.
0 Disableddrive disabled
1 Enableddrive enabled
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.21 1068Startstatemon BIT 16 0 0 1 R FVS
The drive Start command status is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.22 1070FastStopstatemon BIT 16 0 0 1 R FVS
The drive FastStop command status is displayed.
Menu PAR Descripttion UM Type FB BIT Def Min Max Acc Mod
1.23 1100Digitalinputmon UINT16 16 0 0 0 R FVS
The status of the digital inputs on the drive is displayed. It can also be read via a serial line or eldbus. The
data are contained in a word, where each bit is 1 if voltage is supplied to the corresponding input terminal.
1 Input enabled.
0 Input disabled.
I.e. :
000000000011
Active DI
1
Active DI 2
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.24 1300Digitaloutputmon UINT16 0 0 0 R FVS
The status of the digital outputs on the drive is displayed. It can also be read via a serial line or eldbus. The
data are contained in a word, where each bit is 1 if voltage is supplied to the corresponding input terminal.
1 Output enabled.
0 Output disabled.
I.e. :
000000000011
Active DO
1
Active DO 2
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.25 1200DigitalinputXmon UINT16 16 0 0 0 R FVS
The status of the digital inputs of the expansion card is displayed. It can also be read via a serial line or eld-
bus. The data are contained in a word, where each bit is 1 if voltage is supplied to the corresponding input
terminal. This parameter displays the state of the 16 external inputs. The 14 less signicant bits are displayed
from the keypad.
1 Input enabled.
0 Input disabled.
I.e. :
000000000011
Active DI
1
Active DI 2
