10 ADV200 • Functions description and parameters list
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.7 260 Motorspeed FF INT16 16/32 0 0 0 R FVS
The actual output speed of the motor is displayed (in Flux vector CL = speed measured by the encoder, in Flux
vector OL / V/f control = speed estimated by the drive).
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.8 270 DClinkvoltage V FLOAT 16/32 0.0 0.0 0.0 ER FVS
The direct voltage of the intermediate circuit capacitors is displayed (DC-Bus).
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.9 272 Heatsinktemperature degC INT16 16 0 0 0 ER FVS
The temperature measured on the drive heatsink is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.10 290 Motortemperature degC FLOAT 16BIT 0.0 0.0 0.0 ER FVS
Displays motor temperature in °C based on type of sensor selected to manage the alarm.
Equals 0 when direct conversion from count/ohm to °C is not possible, for example with PTC sensors.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.11 1610Aninp1Xtempmon degC FLOAT 16BIT 0.0 0.0 0.0 ER FVS
1.12 1660Aninp2Xtempmon degC FLOAT 16BIT 0.0 0.0 0.0 ER FVS
Displays temperature in °C with PT100/PT1000/NI1000 from input 1 (PAR 1610) or input 2 (PAR 1660) of EXP-
IO-SENS-100-ADV or EXP-IO-SENS-1000-ADV card, regardless of how the motor overtemperature alarm is
managed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.13 280 Torquecurrentref A FLOAT 16/32 0.0 0.0 0.0 ER F_S
The current reference used for torque control is displayed (in the Flux vector OL and Flux vector CL
modes
).
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.14 282 Magnetcurrentref A FLOAT 16/32 0.0 0.0 0.0 ER F_S
The magnetizing current reference is displayed
(in the Flux vector OL and Flux vector CL
modes
).
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.15 284 Torquecurrent A FLOAT 16/32 0.0 0.0 0.0 ER FVS
The actual torque current value is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.16 286 Magnetcurrent A FLOAT 16/32 0.0 0.0 0.0 ER FVS
The actual magnetizing current value is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.17 3212Motoroverloadaccum perc UINT16 16/32 0 0 100 ER FVS
The motor overload level is displayed (100% = alarm threshold).
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.18 368 Driveoverloadaccum perc UINT16 16/32 0 0 100 ER FVS
The drive overload level is displayed. An instantaneous overload of 180% of the drive rated current is allowed
for 3 s. The thermal image I²t adjusts the drive output current thresholds. During normal operation, the instan-
taneous output current value can reach 180% of the drive rated current. After 0,5 s at 180%, the output current
threshold is reduced to 160%. When the overload level par.368Driveoverloadaccum reaches 100%, the
output current threshold is reduced to 100% of the rated current, and stays at that value until the I²t integrator
cycle is complete. At this point the 180% instantaneous overload is re-enabled.
