gefran ADV200 Functions Description And Parameters List

14 ADV200 • Functions description and parameters list
2 90.0/110.0 kW 3 690V
3 110.0/132.0 kW 3 690V
4 132.0/160.0 kW 3 690V
5 160.0 kW 3 690V
6 200.0 kW 3 690V
7 250.0 kW 3 690V
8 315.0 kW 3 690V
9 355.0 kW 3 690V
10 400.0 kW 3 690V
11 500.0 kW 3 690V
12 630.0 kW 3 690V
13 710.0 kW 3 690V
14 800.0 kW 3 690V
15 1000.0 kW 3 690V
16 1200.0 kW 3 690V
17 160.0/200.0 kW 3 690V
18 200.0/250.0 kW 3 690V
19 250.0/315.0 kW 3 690V
20 315.0/355.0 kW 3 690V
21 355.0/400.0 kW 3 690V
22 400.0/500.0 kW 3 690V
23 500.0/630.0 kW 3 690V
24 630.0/710.0 kW 3 690V
25 710.0/800.0 kW 3 690V
26 0.9/1.0 MW 3 690V
27 1.0/1.2 MW 3 690V
28 1.35/1.5 MW 3 690V
29 1.65/1.8 MW 3 690V
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
2.3 484 Drivefamily ENUM No Power 0 0 RS FVS
The available mains voltage is displayed (e.g. 400V). The undervoltage alarm refers to this voltage value.
The condition No power occurs when the regulation board has just left from production and has never been
congured for any power. The conguration adjustment for a given power is achieved by linking it to a power
board and running a Saveparameters.
0 No Power
1 380V…480V
2 500V…575V
3 690V
4 230V
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
2.4 486 Driveregion ENUM EU 0 1 R FVS
The geographical area (Europe or USA) is displayed. The factory settings for the power supply voltage and
frequency used by the drive are dened accordingly.
0 EU (400V / 50Hz)
1 USA (460 / 60 Hz)
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
2.5 488 Drivecontcurrent A FLOAT CALCF 0.0 0.0 RZS FVS
The current that the drive can deliver continuously according to size, supply voltage and programmed switching
frequency is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
2.6 490 Firmwarever.rel UINT16 0 0 0 R FVS
