ADV200 • Functions description and parameters list 147
rameter is a oat-type parameter not in real time (5-10ms)
Note! If the sys parameter is notassigned, none of the subsequent fieldbus channels are read, even if programmed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
23.3.3 4024FieldbusM->S1mon INT32 32 0 0 0 ER FVS
23.3.7 4034FieldbusM->S2mon INT32 32 0 0 0 ER FVS
23.3.11 4044FieldbusM->S3mon INT32 32 0 0 0 ER FVS
23.3.15 4054FieldbusM->S4mon INT32 32 0 0 0 ER FVS
23.3.19 4064FieldbusM->S5mon INT32 32 0 0 0 ER FVS
23.3.23 4074FieldbusM->S6mon INT32 32 0 0 0 ER FVS
23.3.27 4084FieldbusM->S7mon INT32 32 0 0 0 ER FVS
23.3.31 4094FieldbusM->S8mon INT32 32 0 0 0 ER FVS
23.3.35 4104FieldbusM->S9mon INT32 32 0 0 0 ER FVS
23.3.39 4114FieldbusM->S10mon INT32 32 0 0 0 ER FVS
23.3.43 4124FieldbusM->S11mon INT32 32 0 0 0 ER FVS
23.3.47 4134FieldbusM->S12mon INT32 32 0 0 0 ER FVS
23.3.51 4144FieldbusM->S13mon INT32 32 0 0 0 ER FVS
23.3.55 4154FieldbusM->S14mon INT32 32 0 0 0 ER FVS
23.3.59 4164FieldbusM->S15mon INT32 32 0 0 0 ER FVS
23.3.63 4174FieldbusM->S16mon INT32 32 0 0 0 ER FVS
The value received from the bus is displayed. This parameter must be associated with the src parameter to en-
able the M->S channel.
The user may modify the M->Sand by S->Msys parameters. The consistency of the sys with the parameter
assigned to the channel is checked.
AFieldbusM->SXMonparametercanonlybeassignedtoasingle“src”.Ifassignedtomorethanone
src,anerrorsignalisgeneratedduringeldbusinitialization.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
23.3.4 4026FieldbusM->S1div FLOAT 1.0 1.0 1000.0 ERW FVS
23.3.8 4036FieldbusM->S2div FLOAT 1.0 1.0 1000.0 ERW FVS
23.3.12 4046FieldbusM->S3div FLOAT 1.0 1.0 1000.0 ERW FVS
23.3.16 4056FieldbusM->S4div FLOAT 1.0 1.0 1000.0 ERW FVS
23.3.20 4066FieldbusM->S5div FLOAT 1.0 1.0 1000.0 ERW FVS
23.3.24 4076FieldbusM->S6div FLOAT 1.0 1.0 1000.0 ERW FVS
23.3.28 4086FieldbusM->S7div FLOAT 1.0 1.0 1000.0 ERW FVS
23.3.32 4096FieldbusM->S8div FLOAT 1.0 1.0 1000.0 ERW FVS
23.3.36 4106FieldbusM->S9div FLOAT 1.0 1.0 1000.0 ERW FVS
23.3.40 4116FieldbusM->S10div FLOAT 1.0 1.0 1000.0 ERW FVS
23.3.44 4126FieldbusM->S11div FLOAT 1.0 1.0 1000.0 ERW FVS
23.3.48 4136FieldbusM->S12div FLOAT 1.0 1.0 1000.0 ERW FVS
23.3.52 4146FieldbusM->S13div FLOAT 1.0 1.0 1000.0 ERW FVS
23.3.56 4154FieldbusM->S14div FLOAT 1.0 1.0 1000.0 ERW FVS
23.3.60 4166FieldbusM->S15div FLOAT 1.0 1.0 1000.0 ERW FVS
23.3.64 4176FieldbusM->S16div FLOAT 1.0 1.0 1000.0 ERW FVS
The DivM->Sxeldbus parameters can be used to increase the resolution of the datum sent on the bus to the
drive in the corresponding channel in EU and EU_oat exchange mode. The parameter value is used by the
drive as the divider of the incoming datum, so that a number with decimal digits can be transferred.
