146 ADV200 • Functions description and parameters list
Setting of the parameter to associate with the bus channel. The default setting is 0, which means channel not
active.
If the parameter to be connected is a sorg (source), the channel and parameter can also be associated by
modifying the sorg parameter in its menu.
When setting a parameter, the format is also automatically set in the sys parameter.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
23.3.2 4022FieldbusM->S1sys ENUM Not assigned 0 10 RW FVS
23.3.6 4032FieldbusM->S2sys ENUM Not assigned 0 10 RW FVS
23.3.10 4042FieldbusM->S3sys ENUM Not assigned 0 10 RW FVS
23.3.14 4052FieldbusM->S4sys ENUM Not assigned 0 10 RW FVS
23.3.18 4062FieldbusM->S5sys ENUM Not assigned 0 10 RW FVS
23.3.22 4072FieldbusM->S6sys ENUM Not assigned 0 10 RW FVS
23.3.26 4082FieldbusM->S7sys ENUM Not assigned 0 10 RW FVS
23.3.30 4092FieldbusM->S8sys ENUM Not assigned 0 10 RW FVS
23.3.34 4102FieldbusM->S9sys ENUM Not assigned 0 10 RW FVS
23.3.38 4112FieldbusM->S10sys ENUM Not assigned 0 10 RW FVS
23.3.42 4122FieldbusM->S11sys ENUM Not assigned 0 10 RW FVS
23.3.46 4132FieldbusM->S12sys ENUM Not assigned 0 10 RW FVS
23.3.50 4142FieldbusM->S13sys ENUM Not assigned 0 10 RW FVS
23.3.54 4152FieldbusM->S14sys ENUM Not assigned 0 10 RW FVS
23.3.58 4162FieldbusM->S15sys ENUM Not assigned 0 10 RW FVS
23.3.62 4172FieldbusM->S16sys ENUM Not assigned 0 10 RW FVS
Setting of the format of the datum received on the channel. When the src parameter is programmed, the for-
mat is automatically programmed on the relative sys. If the src parameter is reset to null, the format does not
change. The value of the format can be selected from the following list, according to the parameter selected as
the source:
0 Not assigned
1 Count 16
2 Count 32
3 Fill 16
4 Fill 32
5 Mdplc 16
6 Mdplc 32
7 Eu
8 Eu oat
9 Par 16
10 Par 32
If set to 0 the channel is not assigned.
If set to 1 the datum is assigned a 16-bit count.
If set to 2 the datum is assigned a 32-bit count.
If set to 3 16 bits on the channel are reserved for the datum, not used.
If set to 4 32 bits on the channel are reserved for the datum, not used.
If set to 5 the datum is assigned a 16-bit count used by MDPLC.
If set to 6 the datum is assigned a 32-bit count used by MDPLC.
If set to 7 the datum is assigned engineering units on a 16-bit integer.
If set to 8 the datum is assigned engineering units on a 32-bit integer.
If set to 9, the datum is assigned a 16-bit integer engineering unit format not in real time (5-10ms)
If set to 10 the datum is assigned a 32-bit integer engineering unit format or oat format if the associated pa-
