150 ADV200 • Functions description and parameters list
rameter is a oat-type parameter not in real time (5-10ms)
Note ! If the sys parameter is notassigned, none of the subsequent channels are transferred to the fieldbus, even if programmed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
23.4.3 4184DigFieldbusS->M1 INT32 32 0 0 0 ERW FVS
23.4.7 4194DigFieldbusS->M2 INT32 32 0 0 0 ERW FVS
23.4.11 4204DigFieldbusS->M3 INT32 32 0 0 0 ERW FVS
23.4.15 4214DigFieldbusS->M4 INT32 32 0 0 0 ERW FVS
23.4.19 4224DigFieldbusS->M5 INT32 32 0 0 0 ERW FVS
23.4.23 4234DigFieldbusS->M6 INT32 32 0 0 0 ERW FVS
23.4.27 4244DigFieldbusS->M7 INT32 32 0 0 0 ERW FVS
23.4.31 4254DigFieldbusS->M8 INT32 32 0 0 0 ERW FVS
23.4.35 4264DigFieldbusS->M9 INT32 32 0 0 0 ERW FVS
23.4.39 4274DigFieldbusS->M10 INT32 32 0 0 0 ERW FVS
23.4.43 4284DigFieldbusS->M11 INT32 32 0 0 0 ERW FVS
23.4.47 4294DigFieldbusS->M12 INT32 32 0 0 0 ERW FVS
23.4.51 4304DigFieldbusS->M13 INT32 32 0 0 0 ERW FVS
23.4.55 4314DigFieldbusS->M14 INT32 32 0 0 0 ERW FVS
23.4.59 4324DigFieldbusS->M15 INT32 32 0 0 0 ERW FVS
23.4.63 4334DigFieldbusS->M16 INT32 32 0 0 0 ERW FVS
If associated with the relative src, the value of this parameter is sent to the bus.
The user may modify the M->S and by S->M sys parameters. The consistency of the sys with the parameter
assigned to the channel is checked.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
23.4.4 4186FieldbusS->M1mul FLOAT 1.0 1.0 1000.0 ERW FVS
23.4.8 4196FieldbusS->M2mul FLOAT 1.0 1.0 1000.0 ERW FVS
23.4.12 4206FieldbusS->M3mul FLOAT 1.0 1.0 1000.0 ERW FVS
23.4.16 4216FieldbusS->M4mul FLOAT 1.0 1.0 1000.0 ERW FVS
23.4.20 4226FieldbusS->M5mul FLOAT 1.0 1.0 1000.0 ERW FVS
23.4.24 4236FieldbusS->M6mul FLOAT 1.0 1.0 1000.0 ERW FVS
23.4.28 4246FieldbusS->M7mul FLOAT 1.0 1.0 1000.0 ERW FVS
23.4.32 4256FieldbusS->M8mul FLOAT 1.0 1.0 1000.0 ERW FVS
23.4.36 4266FieldbusS->M9mul FLOAT 1.0 1.0 1000.0 ERW FVS
23.4.40 4276FieldbusS->M10mul FLOAT 1.0 1.0 1000.0 ERW FVS
23.4.44 4286FieldbusS->M11mul FLOAT 1.0 1.0 1000.0 ERW FVS
23.4.48 4296FieldbusS->M12mul FLOAT 1.0 1.0 1000.0 ERW FVS
23.4.52 4306FieldbusS->M13mul FLOAT 1.0 1.0 1000.0 ERW FVS
23.4.56 4316FieldbusS->M14mul FLOAT 1.0 1.0 1000.0 ERW FVS
23.4.60 4326FieldbusS->M15mul FLOAT 1.0 1.0 1000.0 ERW FVS
23.4.64 4336FieldbusS->M16mul FLOAT 1.0 1.0 1000.0 ERW FVS
The “FieldbusS->Mxmul” parameters are multipliers that the drive applies to the datum before sending it to
the bus. It is therefore possible to increase the resolution of some values read in EU and EU_oat mode, also
using decimal digits.
N.B.: The drive does not check that the multiplied parameter expressed in bits ts in a 16-bit integer. You must
make sure that the multiplier is compatible with the maximum value of the exchanged parameter and that it
