ADV200 • Functions description and parameters list 149
23.4.49 4300FieldbusS->M13ipa FBM2SIPA 0 0 20000 RW FVS
23.4.53 4310FieldbusS->M14ipa FBM2SIPA 0 0 20000 RW FVS
23.4.57 4320FieldbusS->M15ipa FBM2SIPA 0 0 20000 RW FVS
23.4.61 4330FieldbusS->M16ipa FBM2SIPA 0 0 20000 RW FVS
Setting of the parameter to associate with the bus channel. The default setting is 0, which means channel not active.
When setting a parameter, the format is also automatically set in the sys parameter
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
23.4.2 4182FieldbusS->M1sys ENUM Not assigned 0 10 RW FVS
23.4.6 4192FieldbusS->M2sys ENUM Not assigned 0 10 RW FVS
23.4.10 4202FieldbusS->M3sys ENUM Not assigned 0 10 RW FVS
23.4.14 4212FieldbusS->M4sys ENUM Not assigned 0 10 RW FVS
23.4.18 4222FieldbusS->M5sys ENUM Not assigned 0 10 RW FVS
23.4.22 4232FieldbusS->M6sys ENUM Not assigned 0 10 RW FVS
23.4.26 4242FieldbusS->M7sys ENUM Not assigned 0 10 RW FVS
23.4.30 4252FieldbusS->M8sys ENUM Not assigned 0 10 RW FVS
23.4.34 4262FieldbusS->M9sys ENUM Not assigned 0 10 RW FVS
23.4.38 4272FieldbusS->M10sys ENUM Not assigned 0 10 RW FVS
23.4.42 4282FieldbusS->M11sys ENUM Not assigned 0 10 RW FVS
23.4.46 4292FieldbusS->M12sys ENUM Not assigned 0 10 RW FVS
23.4.50 4302FieldbusS->M13sys ENUM Not assigned 0 10 RW FVS
23.4.54 4312FieldbusS->M14sys ENUM Not assigned 0 10 RW FVS
23.4.58 4322FieldbusS->M15sys ENUM Not assigned 0 10 RW FVS
23.4.62 4332FieldbusS->M16sys ENUM Not assigned 0 10 RW FVS
When setting the sorg parameter the format is automatically set on the relative sys. If sorg is set to null, the
data format does not change. The value of the format can be selected from the following list, according to the
parameter selected as the source:
0 Not assigned
1 Count 16
2 Count 32
3 Fill 16
4 Fill 32
5 Mdplc 16
6 Mdplc 32
7 Eu
8 Eu oat
9 Par 16
10 Par 32
If set to 0 the channel is not assigned.
If set to 1 the datum is assigned a 16-bit count.
If set to 2 the datum is assigned a 32-bit count.
If set to3 16 bits on the channel are reserved for the datum, not used.
If set to 4 32 bits on the channel are reserved for the datum, not used.
If set to5 the datum is assigned a 16-bit count used by MDPLC.
If set to 6 the datum is assigned a 32-bit count used by MDPLC.
If set to 7 the datum is assigned engineering units on a 16-bit integer.
If set to 8 the datum is assigned engineering units on a 32-bit integer.
If set to 9, the datum is assigned a 16-bit integer engineering unit format not in real time (5-10ms)
If set to 10 the datum is assigned a 32-bit integer engineering unit format or oat format if the associated pa-
