158 ADV200 • Functions description and parameters list
Not all alarms allow the controlled stopping of the drive. The following table shows the possibility of setting the Activi-
ties for the individual alarm signals.
Alarm Ignore Warning Disabledrive Stop Faststop
ExtFlt
ü ü ü ü ü
Motor OT
ü ü ü ü ü
Overspeed
ü ü ü ü ü
SpdRefLoss
ü ü ü ü ü
SpdFbkLoss
ü ü ü ü ü
Drive ovld
ü ü ü ü ü
Motor ovld
ü ü ü ü ü
Bres ovld
ü ü ü ü ü
HTsens - -
ü ü ü
InAir
ü ü ü ü ü
Desat - -
ü
- -
IOverC - -
ü
- -
OverV - -
ü
- -
UnderV - -
ü
- -
PhLoss
ü ü ü ü ü
Bus option
ü ü ü ü ü
GroundFault thr - -
ü
- -
Brake fault
ü ü ü ü ü
EXT IO
ü ü ü ü ü
FL faukt
ü ü ü ü ü
Missing Motor phase
ü ü ü ü ü
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
24.1 4500Faultresetsrc LINK 16 1120 0 16384 RW FVS
Selection of the origin (source) of the signal to be used for the command to reset the drive after an alarm. The
terminal that can be used for this function can be selected from among those listed in the “L_DIGSEL2” selec-
tion list.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
24.2 4502ExtFltsrc LINK 16 6000 0 16384 RW FVS
Selection of the origin (source) of the signal to be used as the input for the drive external fault alarm ExtFlt.
The terminal that can be used for this function can be selected from among those listed in the “L_DIGSEL2”
selection list.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
24.3 4504ExtFltactivity ENUM Disable 0 4 RW FVS
Setting of the behaviour of the drive in the event of an external fault alarm ExtFlt. This alarm indicates the inter-
vention of a drive external protection.
0 Ignore
1 Warning
2 Disable
3 Stop
4 Fast stop
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
24.4 4506ExtFltrestart ENUM Disable 0 1 RW FVS
Enabling of automatic restart after the external fault alarm ExtFlt
0 Disable
1 Enable
