160 ADV200 Functions description and parameters list
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
24.13 4528MotorOTholdoff ms UINT16 1000 0 30000 RW FVS
Setting of the delay between the signalling of the motor overtemperature alarm MotorOT and enabling of the
alarm. If an alarm condition occurs, the drive will wait for the set time before enabling the alarm. If the alarm is
removed within the set time, the drive will not indicate any alarm condition.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
24.14 4530MotorOTprobe ENUM SRC 0 8 ERW FVS
Selection of type of sensor for measuring external temperature. The following can be selected:
0 SRC alarm managed via IPA 4520 MotorOTsrc
1 Sens An1X alarm managed via PT100/PT1000/NI1000read by input 1 expansion card (*)
2 Sens An2X alarm managed via PT100/PT1000/NI1000 read by input 2 expansion card (*)
3 KTY84 AnX alarm managed via KTY84 read by dedicated input for cards (*)
4 PTC AnX alarm managed via PTC read by dedicated input for cards (*)
5 KTY84 An1 alarm managed via KTY84 read by analog input 1 of control card
6 KTY84 An2 alarm managed via KTY84 read by analog input 2 of control card
7 PTC An1 alarm managed via PTC read by analog input 1 of control card
8 PTC An2 alarm managed via PTC read by analog input 2 of control card
(*) = EXP-IO-SENS-100-ADV, EXP-IO-SENS-1000-ADV.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
24.15 4532MotorOTthr cnt UINT16 0 0 32767 ERW FVS
Represents the resistance threshold at which the “MotorOT” alarm must trip.
The parameter is expressed in counts or ohms depending on the type of sensor selected (ohms only when
selecting KTY84 An1, KTY84 An2, PTC An1, PTC An2).
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
24.16 4536MotorOTmon cnt INT16 0 0 32767 ER FVS
Represents the resistance measurement monitor.
The parameter is expressed in counts or ohms depending on the type of sensor selected (ohms only when
selecting KTY84 An1, KTY84 An2, PTC An1, PTC An2).
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
24.17 4540Overspeedthreshold rpm INT32 CALCI 0 CALCI RW FVS
Setting of the threshold above which the overspeed alarm Overspeed is enabled.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
24.18 4542Overspeedactivity ENUM Disable 0 4 RW FVS
Setting of the behaviour of the drive in case of a motor overspeed alarm Overspeed. This alarm indicates that
the motor speed has exceeded the threshold set in the Speedreftoplimand Speedrefbottomlim param-
eters in the COMMANDS menu.
0 Ignore
1 Warning
2 Disable
3 Stop
4 Fast stop
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
24.19 4544Overspeedholdoff ms UINT16 0 0 5000 RW FVS
Setting of the delay between the signalling of the motor overspeed alarm Overspeed and enabling of the
alarm. If an alarm condition occurs, the drive will wait for the set time before enabling the alarm. If the alarm is
removed within the set time, the drive will not indicate any alarm condition.
