178 ADV200 • Functions description and parameters list
7 1 = PLC 8 fault active
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5800FLFwd1invmon INT32 32BIT 0 0 0 ER
5802FLFwd2invmon INT32 32BIT 0 0 0 ER
5804FLFwd3invmon INT32 32BIT 0 0 0 ER
5806FLFwd4invmon INT32 32BIT 0 0 0 ER
5808FLFwd5invmon INT32 32BIT 0 0 0 ER
5810FLFwd6invmon INT32 32BIT 0 0 0 ER
5812FLFwd7invmon INT32 32BIT 0 0 0 ER
5814FLFwd8invmon INT32 32BIT 0 0 0 ER
These parameters are not used on the master drive.
On the slave drive these parameters show the value received from the previous drive. The “ Inv” parameters
enable the value received to be used with the opposite sign, without changing any of the data sent to subse-
quent slaves.
These parameters are available in the “src” analog parameter selection lists.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
6000Null UINT32 32 0 0 0 ER
This signal forces the variable to the zero level (always disabled).
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
6002One UINT32 32 1 1 1 ER
This signal forces the variable to level one (always active).
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
6004Speedlimitstate BIT 16 0 0 1 ER
This signal is activated when the drive is in the speed limit condition.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
6006Currentlimitstate BIT 16 0 0 1 ER
This signal is activated when the drive is in the current limit condition.
