ADV200 • Parameters List 223
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
17 5900 (380V..480V)
18 61100 (380V..480V)
19 61320 (380V..480V)
20 71600 (380V..480V)
21 72000 (380V..480V)
22 72500 (380V..480V)
23 73150 (380V..480V)
24 73550 (380V..480V)
25 400.0 kW (380V..480V)
26 500.0 kW (380V..480V)
27 630.0 kW (380V..480V)
28 710.0 kW (380V..480V)
29 900.0 kW (380V..480V)
30 1000.0 kW (380V..480V)
1 5750 (690V)
2 6900 (690V)
3 61100 (690V)
4 61320 (690V)
5 71600 (690V)
6 72000 (690V)
7 72500 (690V)
8 73150 (690V)
9 73550 (690V)
10 400.0 kW (690V)
11 500.0 kW (690V)
12 630.0 kW (690V)
13 710.0 kW (690V)
14 800.0 kW (690V)
15 1000.0 kW (690V)
16 1200.0 kW (690V)
2.3 484 Drive family ENUM No power 0 0 RS FVS
0 No power
1 380V..480V
2 500V..575V
3 690V
4 230V
2.4 486 Drive region ENUM EU 0 1 R FVS
0 EU
1 USA
2.5 488 Drive cont current A FLOAT CALCF 0.0 0.0 RZS FVS
2.6 490 Firmware ver.rel UINT16 0 0 0 R FVS
2.7 496 Firmware type UINT16 0 0 0 R FVS
2.8 504 Application ver.rel UINT16 0 0 0 ER FVS
2.9 506 Application type UINT16 0 0 0 ER FVS
2.10 510 Time drive power on h.min UINT32 0 0 0 ER FVS
2.11 512 Time drive enable h.min UINT32 0 0 0 ER FVS
2.12 514 Number power up UINT16 0 0 0 ER FVS
2.13 516 Time fan on h.min UINT32 0 0 0 ER FVS
2.14 526 Power file ver.rel UINT16 0 0 0 ER FVS
2.15 530 Slot1 card type ENUM None 0 0 R FVS
0 None
769 I/O 1
1793 I/O 2
2305 I/O 3
3329 I/O 4
1544 Enc 1
1800 Enc 2
520 Enc 3
776 Enc 4
1032 Enc 5
