28 ADV200 • Functions description and parameters list
Selection of the origin (source) of the drive speed reference signals. The values that can be used as speed
references can be selected from those listed in the “L_MLTREF” selection list.
When assigning the reference via terminals, signals with ±10V, 0 ...10V, 0... 20 mA and 4 ... 20 mA can be
used.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.19 654 Speedrefinvertsrc LINK 16 6000 0 16384 ERWZ FVS
Selection of the origin (source) of the signal that inverts the speed reference output from the regulator. The ter-
minal that can be used for this function can be selected from among those listed in the “L_DIGSEL2” selection
list.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.20 660 Speedref1mon FF INT16 0 0 0 ER FVS
5.21 662 Speedref2mon FF INT16 0 0 0 ER FVS
The value of the relative speed reference is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.22 670 Speedreftoplim FF INT32 CALCI 0 CALCI ERWZ FVS
Setting of the upper speed reference limit. If the speed reference exceeds the limits, the motor speed remains
at the set limit value in any case. Speed limits cannot be more than 200% of the value set in the Fullscale
speed parameter (REFENCES menu par. 680).
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.23 672 Speedrefbottomlim FF INT32 CALCI CALCI 0 ERWZ FVS
Setting of the lower speed reference limit. If the speed reference exceeds the limits, the motor speed remains
at the set limit value in any case. Speed limits cannot be more than 200% of the value set in the Fullscale
speed parameter (REFERENCES menu par. 680).
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.24 666 Speedreffilter ms UINT16 0 0 1000 ERW FVS
Filter to the speed reference value. If IPA 666 Speedreflter is set to 0, lter is disabled.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.25 680 Fullscalespeed rpm INT16 CALCI 50 32000 RWZ FVS
Setting of the reference value for all speed percentage data (References, Speed adaptives ...) corresponding
to 100 % of the actual speed. This parameter can only be changed with the inverter blocked (Enable drive =
Disabled). The recommended setting for the value of this parameter is the motor rated speed. If altered, the
self-tuning procedure should be repeated.
Fullscalespeed does not dene the maximum possible speed. In any case, the maximum
speed percentage value is ± 200 % of the Fullscalespeed value.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.26 222 Thetarefsrc LINK 16/32 220 0 16384 ERW F_S
Selection of the origin (source) of the ux reference. Value can be selected from among those listed in the
“L_MLTREF” selection list.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.27 224 Fluxrefmon LINK 16/32 224 0 16384 ERW F_S
Selection of the origin (source) of electrical agle of the motor. Value can be selected from among those listed in
the “L_MLTREF” selection list.
