ADV200 • Functions description and parameters list 37
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
8.1 870 Mpotsetpoint rpm INT16 16/32 0 CALCI CALCI R FVS
The speed reference value of the Motor potentiometer function is displayed.
Enter this parameter to send the UP and DOWN commands from the keypad.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
8.2 872 Mpotacceleration s FLOAT 5.0 0.01 1000.00 RW FVS
8.3 874 Mpotdeceleration s FLOAT 5.0 0.01 1000.00 RW FVS
Setting of the acceleration/deceleration ramp times (in seconds) used with the Motor potentiometer function.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
8.4 876 Mpottoplim rpm INT16 CALCI CALCI CALCI ERW FVS
Setting of the top limit for the speed reference output from the motor potentiometer.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
8.5 878 Mpotbottomlimit rpm INT16 0 CALCI CALCI ERW FVS
Setting of the bottom limit for the speed reference output from the motor potentiometer.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
8.6 880 Mpotinitcfg ENUM Zero 0 3 ERW FVS
Use this parameter to congure the output value of the Motor potentiometer at drive start-up.
0 Last power off
1 Zero
2 Lower Limit
3 Upper Limit
When set to Lastpoweroff, the motor potentiometer output starts from the last frequency that was set before
the drive was switched off.
When set to Zero the motor potentiometer output starts from a value of 0.
When set to Lowerlimit the output of the motor potentiometer starts from the value of the lower limit set in the
Mpotbottomlimit parameter.
When set to Upperlimit the output of the motor potentiometer starts from the value of the upper limit set in the
Mpottoplimit parameter.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
8.7 882 Mpotpresetcfg ENUM None 0 11 ERW FVS
This parameter can be used to congure the preset of the Motor potentiometer function, i.e. to congure the
value at which the Motor potentiometer input and output are set when the Preset command is enabled.
The Preset command has priority over the Up command and the Down command.
Mpotmode (PAR 892) = [1] Ramp&Follow has priority over the Preset command, i.e. actions programmed
with Mpotpresetcfg (PAR 882) are not executed.
The Up and Down commands are enabled again when the Preset command is disabled.
0 None
1 Input = 0
2 Input = low lim
3 Input & ref = 0
4 Input & ref = low lim
5 Output = 0
6 Output = low lim
