56 ADV200 • Functions description and parameters list

A relay (K1) can be used to repeat the safety card feedback signal. A normally

open (NO) contact of the relay can be connected to a drive input set to “DrvInterlocksrc”.

If the Safetycardisactive (the drive does not supply current) the Safety Enable Feedback digital output is set

to low (0), the relay is not excited and the NO contact is open.

When the “Drv interlock” signal receives a low command (0) (Drive interlock active) the drive is disabled.

The “DrvInterlocksrc” can be used to know the instantaneous state of the Safety Enable Feedback function.

The “Drvinterlockmon” parameter can be used to know the state of the Safety Enable Feedback function tak-

ing into account the interlocking logic with the drive Enable command.

0 Drive interlock active (the Safety card is active)

1 Drive interlock not active (the Safety card is not active)

In “Drvinterlockmon” the Drive interlock state remains active until the Safety card is deactivated and the “En-

able” and “Start” commands are set to low (0).

The drive remains disabled until the “Drv Interlock” commandis set to the high state (1) (Drive interlock not ac-

tive) and the “Enable” and “Start” commands to the low state (0) (Disabled and Stop) and then to the high state

(1).

If the Safetycardisnotactive(the drive can supply current) the Safety Enable Feedback digital output is set

to high (1), the relay is excited and the NO contact is closed.

The “Drv interlock” signal receives a high (1) signal ( Drive interlock not active), the drive can be enabled by

applying the drive enable command.

Menu PAR Descrizione UM Tipo FB BIT Def Min Max Acc Mod

11.24 1034Drvinterlockmon BIT 16 0 0 1 ER FVS

In “Drvinterlockmon” the Drive interlock state remains active until the Safety card is deactivated and the “En-

able” and “Start” commands are set to low (0).

Menu PAR Descrizione UM Tipo FB BIT Def Min Max Acc Mod

11.25 1036FastStopmode ENUM Not Latched 0 1 ERW FVS

This parameter is used to select the operating mode of the FastStop command.

0 Not Latched

1 Latched

If set to 0 (Not Latched), the FastStop command is not stored. Therefore, if the FastStop command is removed

the drive automatically restarts.

If set to 1 (Latched) the FastStop command is stored. If the FastStop command is removed, the drive will not

restart automatically. It can only restart after removing the FastStop command and sending a new Enable and

Start command.
