gefran ADV200 Functions Description And Parameters List

82 ADV200 • Functions description and parameters list
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
17.1 2100Encoder1pulses ppr UINT16 CALCI CALCI CALCI RWZ FVS
Setting of the number of feedback encoder impulses.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
17.2 2102Encoder1supply V FLOAT 5.2 5.2 CALCF ERWZ FVS
Setting of the encoder supply voltage supplied by the relative optional card. Min and max values are modied
according to the type of encoder card applied.
Encoder option type Def Min Max
Enc1 EXP-DE-I1R1F2-ADV 5.2V 5.2V 20.0V
Enc2 EXP-SE-I1R1F2-ADV 5.2V 5.2V 6.0V
Enc3 EXP-SESC-I1R1F2-ADV 5.2V 5.2V 6.0V
Enc4 EXP-EN/SSI-I1R1F2-ADV 5.2V 5.2V 10.0V
Enc5 EXP-HIP-I1R1F2-ADV 8.0V 7.0V 12.0V
Enc6 EXP-RES-I1R1-ADV - - -
Enc7 EXP-DE-I2R1F2-ADV 5.2V 5.2V 20.0V
Enc8 EXP-ASC-I1-ADV 5.2V 5.2V 6.0V
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
17.3 2104Encoder1inputcfg ENUM TTL 0 1 ERWZ FVS
Setting of the input conguration of the incremental digital encoder, TTL or HTL.
0 HTL
1 TTL
The value of this parameter is automatically set in HTL when the value entered in the Encoder1supply pa-
rameter is more than 6.0V.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
17.4 2106Encoder1repetition ENUM No division 0 3 ERWZ FVS
Setting of the divider to apply to the encoder repetition output frequency.
0 No division
1 Divide 2
2 Divide 4
3 Divide 8
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
17.5 2108Encoder1signalVpp V FLOAT 1.0 0.8 1.2 ERWZ FVS
Setting of the encoder signal peak-to-peak voltage value. Incremental sinusoidal encoders and absolute
SinCos encoders normally produce signals with a peak-to-peak voltage of 1 Vpp. Due to voltage drops along
the cable, the signal may have a lower peak-to-peak voltage when it reaches the feedback card, triggering the
Speedfbkloss alarm.
This parameter is used to congure the value of the peak-to-peak voltage of the incremental sinusoidal encod-
ers and absolute SinCos encoders on the input terminals of the feedback card.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
17.6 2110Encoder1signalcheck ENUM Check A-B 0 1 ERWZ FVS
Conguration of which channels of the incremental digital encoder must be controlled for processing the Speed
fbkloss[22].
0 Check disabled
1 Check A-B
2 Check A-B-Z
