gefran ADV200 Functions Description And Parameters List

84 ADV200 • Functions description and parameters list
Menu PAR Descrizione UM Tipo FB BIT Def Min Max Acc Mod
17.12 2120ResolverTratioK FLOAT 0.5 0.2 1.0 ERWZ FVS
Value of the resolver Trasformer ratio of used resolver (see Resolver name plate data).
Menu PAR Descrizione UM Tipo FB BIT Def Min Max Acc Mod
17.13 2122Resolverrepetition ENUM 16384 ppr 0 3 ERWZ FVS
Simulated selection of the resolver repetition.
0 256 ppr
1 1024 ppr
2 4096 ppr
3 16384 ppr
Menu PAR Descrizione UM Tipo FB BIT Def Min Max Acc Mod
17.14 2124ResolverLOSthr V FLOAT 2.200 0.000 4.820 ERWZ FVS
Loss Of Signal threshold: Setting of the lower threshold value of the Resolver signal. Values below this setting
will generate a Speedfbkloss[22] alarm.
Menu PAR Descrizione UM Tipo FB BIT Def Min Max Acc Mod
17.15 2126ResolverOVRthr V FLOAT 4.100 0.000 4.820 ERWZ FVS
Over range Threshold: Setting of the higher threshold value of the Resolver signal. Values higher than this set-
ting will generate a Speedfbkloss[22] alarm.
Menu PAR Descrizione UM Tipo FB BIT Def Min Max Acc Mod
17.16 2128ResolverMISthr V FLOAT 0.380 0.000 4.820 ERWZ FVS
Mismatch value threshold between Sin and Cos signals.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
17.17 2130Encoder1direction ENUM Not inverted 0 1 RWZ FVS
Selection of the encoder direction
0 Not inverted
1 Inverted
By setting 0 the encoder feedback signals are not inverted.
By setting 1 the encoder feedback signals are inverted.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
17.18 2132Encoder1mode ENUM None CALCI CALCI ERWZ FVS
Setting of the method for measuring the speed of the encoder connected to the optional card. The drive auto-
matically recognises the encoder card that is inserted and only shows the methods that are compatible.
0 None
1 Digital FP
2 Digital F
3 Sinus
4 Sinus SINCOS
5 Sinus ENDAT
6 Sinus SSI
7 Sinus HIPER
8 Resolver
9 Abs SINCOS
The speed measurement procedure depends on the type of encoder card; minimum and maximum default
values are set according to the type of feedback card that is applied.
