3030 mFlow
20 Order data
20.1 Order data complete measurement device
K-Number Code
Ra  0.8 m electropolished (internal/external)
surface finish data refer to medium wetted surfaces
(only housing configuration DU, DN) 1503
Supply voltage Code
24 V DC C1
Option Code
Without option 00
Profibus-DP DP
Order example
3030 000 DH WS 41 4 E M42 00 C1 -
Type 3030
Nominal size (code) 000
Housing configuration (code) DH
Connection (code) WS
Housing material (code) 41
Seal material (code) 4
Sensor material (code ) E
Device version (code) M42
Option (code) 00
Supply voltage (code) C1
K-Number (code) -
Connection Code
GEMÜ weldolet
(only housing configuration DH) WS
Union end with insert (threaded socket Rp) 7R
DIN wafer-type flange
(only housing configuration DF) 8
Butt weld spigot DIN 11850 series 2
(only housing configuration DU, DN) 17
Housing material Code
1.4435 stainless steel 41
Housing configuration Code
Measurement device with GEMÜ in-line housing DD
Measurement device with GEMÜ wafer-type flange DF
Measurement device with GEMÜ weldolet DH
Measurement device with Neumo BioControl
®
in-line housing DN
Measurement device with Tuchenhagen Varivent
®
in-line housing DU
Sensor material Code
1.4435 / PEEK C
1.4435 / TFM 16 E
Seal material Code
FPM (only housing configuration DH, DD, DF) 4
EPDM 14
FFKM (Isolast J9505)
(only housing configuration DH, DD, DF) F5
Device version Code
Measurement device with field bus interfaces
(only for Option DP) M02
Measurement device 4 - 20 mA, 1 pulse output,
2 relay outputs (not for Option DP) M42
Measurement device temperature sensor, 4 - 20 mA,
1 pulse output, 2 relay outputs MT2
CONEXO Code
Without
Integrated RFID chip for electronic identification
and traceability C
