105 GSM19 Series Magnetometers - Version 7
GEM Systems, Inc. Advanced Magnetometers
For more technical information, visit www.gemsys.ca
NOTE
A-send-raw-data and the number of bytes is only visible on mags equipped with
DGPS post-processing option.
Press F-ok after making your choice.
• If GPS no is selected, the software automatically returns to the Main Menu.
• If GPS yes is selected, the unit displays the GPS menu.
SCREEN D3
GPS menu
A-initialize-GPS B-navigation
C-synch-to-UTC D-test
E-post-processing no
F
NOTE
E-post-processing is only visible on units equipped with DGPS post-processing
option.
B-navigation is only visible on units equipped with lane guidance and waypoints
navigation options
Select A-initialize-GPS to initialize the GPS module and start GPS lock.
SCREEN D4
please wait for pps
The message “please wait for pps” , where pps represents
Pulse Per Second, is displayed until GPS
lock occurs. Then the display returns to the GPS menu.
