58 GSM19 Series Magnetometers - Version 7
GEM Systems, Inc. Advanced Magnetometers
For more technical information, visit www.gemsys.ca
Use C-change to select the text labels you want to add to the graph. The options are:
• no text
• field nT
• coordinates
• field nT and coordinates
• grad nT/m
• grad nT/m and coordinates
5.5.4 Selecting Magnetometer Channels
Normally when a GSM-19G gradiometer is used in a single channel mode (i.e. for magnetic
readings only), the lower sensor is used to take the readings but it is also possible to use the upper
channel for this purpose.
To change the channel, access the
Main Menu and press C-info. The following screen is displayed.
SCREEN 51
F - time B - RS232 D - dir
C - review 1 - erase - file
A - remote 0 - datum
E-channel
2 - buzzer 3-info
Press
E – channel. The following screen is displayed.
SCREEN 52
lower
F - ok C - change
C-change toggles between lower and upper (channel). Press F-ok to store your selection.
