117 GSM19 Series Magnetometers - Version 7
GEM Systems, Inc. Advanced Magnetometers
For more technical information, visit www.gemsys.ca
NOTE:
It is advised to use GEMLinkW version 2.4 or higher (as of this release of the
manual, the current version is 3.0). The instructions here correspond to the 2.4
software release. If any of the steps don't match the options or screens available
from your unit, it is either because your unit does not support the waypoint
feature or you have an older software version. Please contact GEM Systems for
assistance.
D.5 SURVEYING WITH GPS NAVIGATION
IMPORTANT NOTES:
The GPS antenna must be connected to the BNC connector MARKED WITH
YELLOW located on the RIGHT HAND SIDE of the console. Do NOT connect
the GPS antenna into the BNC connector for the sensor RF on the left-hand side.
The antenna will be damaged beyond repair.
The GPS antenna MUST be mounted a minimum of one full section staff (56cm)
apart from the sensors to avoid magnetic interference.
Make sure GPS is enabled (GPS yes)
When the GPS is enabled, the positioning system is selected as usual but the options are different.
Press
A for survey and using the F control to toggle the cursor right to Position, press C to change.
The following sequence is an example:
From the Main Menu, press A-survey. The following screen is displayed:
SCREEN D18
A-survey B-diurn.cor
F-GPS
C-info OF-off D-test yes
15 II 00
E-time-synch 1-send TU
00:56:56
45-erase 2-enter text
13.2V
The unit checks for GPS lock
