4.3 DESCRIPTION OF CONNECTORS
SNSR Sensor Channel that receives UPR Upper sensor channel that
the proton precession signal SNSR receives the proton precession
signal.
LWR Lower sensor channel that
SNSR receives the proton precession
signal.
RS232 RS-232 Communication port RS232 RS-232 Communication port
PWR
and input for power PWR and input for power
GSM-19 GSM-19G
MAGNETOMETER
GRADIOMETER
UPR Upper polarization.
PLRZ Sends RF signal, polarizes
the upper sensor.
SNSR Sensor channel that receives UPR Upper sensor channel that
the proton precession signal SNSR receives the proton precession
signal.
PLRZ Polarization, sends RF LWR Lower sensor channel that
signal, polarizes the sensor. SNSR receives the proton precession
signal.
LWR Lower polarization.
PLRZ Sends RF signal, polarizes
the lower sensor.
RS232 RS-232 Communication port RS232 RS-232 Communication port
PWR and input for power. PWR and input for power.
GSM-19W GSM-19GW
“WALKING” MAG “WALKING” GRAD
