5.5.3 Selecting the Display Mode
Press F to highlight display mode. The following screen is displayed.
SCREEN 48 survey mode position time file
cycle time tuning AC filter
display mode text ID sensors
graph
A-start C-change
←
BF
→
Use C-change to switch to the text or graph modes. In graph mode, you can plot either the Total
field (from the lower sensor) or the Gradient.
SCREEN 49
graph
field
display mode
F - ok C - change
C - change toggles between field and grad. Press F-ok to select one. The following screen is
displayed.
SCREEN 50 graph field
no text
display mode
F - ok C - change
