118 GSM19 Series Magnetometers - Version 7
GEM Systems, Inc. Advanced Magnetometers
For more technical information, visit www.gemsys.ca
SCREEN D19
please wait for pps
Select survey mode
SCREEN D20
A-mobile B-Base C-grad
D-walkmag E-walkgrad
To select the position system, highlight position scrolling the cursor with B or F. The current
position is displayed in the selected system.
SCREEN D21 survey mode
position time file
cycle time tuning AC filter
display mode text ID
0000268 0001 0002
629229 4857218 07 - >
A-start C-change
←
BF
→
Where
0000268 - is the distance (in meters) along the current line (wp1 - wp2 direction in this example)
from current location to the ending waypoint (wp2 in this example)
0001 0002 - are the current waypoints.
629229 4857218 are the current coordinates
