5.4.5 Displaying System Information
From the
Reading Menu, press A-menu. The following screen is displayed.
SCREEN 42
A-position B-enter text
4-graph vertical scale
C-tune
5-display-mode
E-EOL F-OK 0-noise
1-info
Then press 1-info. The following screen is displayed.
SCREEN 43
up 2840zc 1200ms 2600 1600
lo 2780zc 1200ms 2500 1600
F
This screen is providing the following information:
• Up - Upper channel (if installed)
• Lo - Lower channel
• 2840zc - # of zero crossings taken (used for measurement calculation)
• 1200ms - Signal measurement time in milliseconds
• 2600 & 1600 - First and last signal measurement amplitudes ( S/N )
