SCREEN 67 50 110 300
600 1200 24000 48000
9600 14400 19200 28800 38400
57600 152000
A-select
←
BF
→
Scroll backward with
B or forward with F and highlight the desired transmission rate (keep pressed
for a continuous scroll).
Press
A-select to save your option. The unit returns to screen 66.
Pressing F-ok leads you to the selection of RS-232 parameters for Real-time Transmission (RTT).
When RTT is enabled, the unit outputs the readings (tagged with their time stamp) to the RS-232 6
pin connector in real time as they are taken.
SCREEN 68
real time RS-232 transmission
yes
F-ok C-change
C-change toggles between yes and no.
• If you do not intend to use the RTT function, select no and press F-ok to return to the Info
Menu. Then press 1C to return to main menu.
• Otherwise select yes and press F-ok . The RTT setting screen is displayed.
To Next Page
