78 GSM19 Series Magnetometers - Version 7
GEM Systems, Inc. Advanced Magnetometers
For more technical information, visit www.gemsys.ca
Press F after your selection. The following screen is displayed.
SCREEN 78
056789.34 000000.0
11:22:33.4
27 IX 96
00100N 0000125E A- B+ C 99
• On line 1: the value to the left is the uncorrected field and the value to the right is the corrected
field
• On line 2: time of the reading [hh:mm:ss.s]
• On line 3: date of the reading [day, month, year]
• On line 4: left - Line # and Station #
A- displays an older reading (current – increment)
B+ displays a newer reading (current + increment)
C displays the change of increment screens
99 represents the signal quality factor
Base files are reviewed in a similar way but the corrected field and the position labels are not
displayed:
SCREEN 79
056789.34
27 IX 96 11:22:33.4
B+ C 99
