Parameter
High byte
Parameter
Low byte
Default Rang Comment
0 200 100 ~800 Minimum sewing speed
1 3500 200 ~5000 Maximum sewing speed
2 3000 200 ~5000 Maximum constant sewing speed
3 3000 200 ~5000 Maximum manual back tacking speed
4 200 100 ~800 Stitch compensation speed
5 250 100 ~500 Trimming speed
6 0
0 ／1
Soft start Mode setup:
0：Soft start only after trimming
1：Soft start after both trimming and stop
7 2 1 ~9 Soft start stitch number
8 200 100 ~800 Soft start speed
9 13 1 ~20
System accelerate sensitivity （ Direct drive
transmission can be set up to a large value；belt
transmission don't set large value or too much
noise and vibration. This parameter do not affect
the electrical）
speed
0
A 13 1 ~20
System decelerate sensitivity（Direct drive
transmission can be set up to a large value；belt
transmission don't set large value or too much
noise and vibration. This parameter do not affect
the electrical ）
0 1800 200 ~3000 Start back tacking speed
1 1800 200 ~3000 End back tacking speed
2 1800 200 ~3000 Continuous back tacking speed
3 26 0 ~70 Start back tacking stitch compensation 1
4 20 0 ~70 Start back tacking stitch compensation 2
5 26 0 ~70 End back tracking stitch compensation 1
Back tacking
setup
1
6 20 0 ~70 End back tracking stitch compensation 2
