Unpacking and Inspection
8 Installation Guidelines for Air-Cooled Generators
2.3 — Unpacking
1. Remove shipping carton. See Figure 2-1.
Figure 2-1. Unpack Generator
2. Remove four bolts with crating clamps. Carefully lift the generator off the wooden pallet. Do NOT drag the gener-
ator off the pallet or damage to the base will occur. See Figure 2-2.
Figure 2-2. Remove Crating Clamps
Wooden
Generator
Frame
15 kW
Lid
Front
Crating Clamps (4)
Access Panel
Pallet
15 kW
To Next Page
