Installation Guidelines for Air-Cooled Generators 27
Section 6 Electrical Connections
6.1 — Generator Connections
NOTE: Wiring must be performed in accordance with local jurisdiction and codes.
1. Remove the appropriate Main AC/Control Wiring knock-out plug at back of generator.
2. Install the generator feeder and control wiring between the generator and inverter or electrical loads to be pow-
ered by the generator per the applicable NEC codes for the wiring method selected. For knock-out plug locations
(verify specific transfer wiring and connections per model), see Figure 2-5.
NOTE: This wiring can be run in the same conduit if the appropriate insulation rated wire is used.
3. Seal the conduit at the generator in compliance with any codes.
4. Strip insulation from wire ends. Do not remove excessive insulation.
5. To connect the control wires, push down on the spring loaded connection point with a flat head screwdriver, insert
wire and release.
NOTE: No wire insulation should be in the connection point, only bare wire.
NOTE: The system is equipped with a 2-wire start to facilitate connection to the inverter system.
6.2 — Control Wiring
Control and 2-wire Start Length and Size
Maximum Wire Length Recommended Wire Size
1-115 ft (1-35 m) No. 18 AWG
116-185 ft (36-56 m) No. 16 AWG
186-295 ft (57-89 m) No. 14 AWG
296-460 ft (90-140 m) No. 12 AWG
Control Pad Connections
Terminal Numbering Decal Wire Numbers
B Blue #3 T1 - Fused 120VAC for Battery Charger
(see NOTE beneath Fig. 6-1 on the following page)
C Black #3 0 - DC (-) Common Ground Wire
2-wire Start Wire Connections
Wire Connection Location
178 Female Faston
Hanging from controller above battery compartment
(see Figure 6-2)
183 Female Faston
