Generac Power Systems GP Series Diagnostic And Repair Manual

Section 1 Description and Components
6 Diagnostic Repair Manual
TORQUE SPECIFICATIONS
Flywheel Nut 150 ft-lbs
Cylinder Head Bolts 22 ft-lbs
Valve Cover Bolts 4.8-5.5 ft-lbs
Rocker Arm Jam Nut 14 ft-lbs
Ignition Coil 9 ft-lbs
Intake Manifold 14 ft-lbs
Exhaust Manifold 14 ft-lbs
Stator Bolts 6 ft-lbs
Rotor Bolt 30 ft-lbs
Spark Plug 15 ft. lbs.
Starter Bracket To Block 18 ft-lbs
TRIM TORQUE SPECIFICATIONS
M3-.5 Phillips Pan Head Screw Into Aluminum 50 in-lbs
M6-1 Taptite Screw Into Aluminum 96 in-lbs
M6-1 Taptite Screw Into Weldnut 96 in-lbs
M8-1.25 Taptite Screw Into Aluminum 18 ft-lbs
