Generac Power Systems XT8000EFI User Manual

Diagnostic Repair Manual iii
Rotor and Stator Resistance Tables
INT* = International Product
Series Model Alternator
Rotor Windings
(Ohms)
Power Windings
(Ohms)
Exciter Windings
(Ohms)
HW
HW3250 5973 0H3578 31 0.62 1.72
6150 0H3578 31 0.62 1.72
HW5500 6036 0J8363 61.48 0.681 2.81
6151 61.48 0.681 2.81
HW5500E 6037 0J8363 61.48 0.681 2.81
HW6500 6038 0K9546 58.95 0.657 2.68
HW7500E 6039 0K0755, 0H9209 49.1-53.01 0.479-0.5 1.37-2.23
6152 0K0755 53.01 0.5 2.233
XC
XC6500
6500
6823
6824
10000007873 52.23 0.346 2.232
XC6500E 6825
XC8000E
6827
6826
XT
XT8000E 6433 0K0755 53.01 0.5 2.233
XT8000E 6434
XT8000EFI 7162 0L0566 52.17± 10% 0.471± 10% 1.626± 10%
HL HL 6500E 6865 0L0608 52.3 0.48 1.37
RS
RS5500
6672
0J8363 61.48 0.681 2.81
6674
RS7000E
6673 0K9547 59.3 0.66 2.23
6675
XG
XG6500 5796 0G8995 63.3 0.53 1.9
XG7000E 5798 0G8990 68.06 0.49 1.93
XG8000E
5747
0K0071 (Brushed) 52.23 0.35 2.235847
5846
XG10000E 5802 0H5064C, 0G5065C 6.3-7.3 0.18-0.21 1.07-1.24
XG INT*
XG5600E 6220 0J8658 48.55 0.83 3.2
XG6400E 6221 0J8659 48 0.48 2.43
XP
XP6500E
5930
5934
0H8886 (Brushed) 72.91 0.518 2.16
XP8000E
5931
0H8887, 0K0071
(Brushed)
74.12 (52.23) 0.342 (0.350) 2.610 (2.230)
5935
XP10000E 5932 0H5064C, 0H5065C 6.3-7.3 0.18-0.21 1.07-1.24
XP INT* 50
Hz
XP5600E 6428 0K1944 49.59 0.68 3.2
XP6400E 6429 0K1945 49.94 0.39 1.97
