4 Rear wheel/rear suspension
Preparation data -----------------4.1
Fault diagnosis -----------------4.2
Rear wheel -----------------4.3
Rear shock absorber/rear rocker ----------4.4
Driving chain -----------------4.5
4.1 Preparation data
Matters needing attention in operation
There cannot be any oil stain stuck to the surface of the brake disc or brake pad.
Preparation reference
Item Standard value （mm） Allowable limit （mm）
Vertical
direction
2.0
Run-out
of rear
wheel
Transverse
direction
2.0
Torque value
Nut of Rear-wheel spindle 85-98 N·m
Topping nut of the rear shock absorber 37-44 N·m
Bottom nut of the rear shock absorber 37-44 N·m
4.2 Fault diagnosis
4.2.1 Run-out of rear wheel
The rim is distorted.
The tyre is not good.
4.2.2 Shock absorber too soft
Elasticity fatigue of spring
