Generic Trigger X 50ccm User Manual

- 69 -
7 Startup system
Preparation data --------------------------7.1
Fault diagnosis ---------------------------7.2
Start electrical machinery ---------------7.3
Start relay ----------------------------------7.4
7.1 Preparation data
Matters needing attention in operation
Disassembly of the start electrical machinery may be conducted on the engine.
Please refer to disassembly operation in disassembly.
Preparation reference
Item Standard value Allowable limit
Brush length of startup motor 12.5mm 8.5mm
Liner of startup idler shaft 8.3mm
Outer diameter of startup idler
shaft
7.94mm
Torque value
Bolt in the clutch cover of the startup electrical machinery 12 N·m
Fixing nut in the clutch of the startup electrical machinery 95 N·m
Tools
Fixing nut spanner
Multiple-use fixing spanner
