Generic Trigger X 50ccm User Manual

- 63 -
6.2 Fault diagnosis
No flashover in spark plug
Abnormal circumstance Cause of badness（confirm in order from 1）
ignition
coil
high voltage too low

The interior resistance is too low and
test it with a designated tester.
The cranking speed is too low.
The tester is disturbed（if the voltage
measured for several times is above
standard, then the value is normal）.
 poor contact of ignition system wire
bad act of the ignition coil
bad act of the charge coil （ peak
voltage test)
no high voltage ， off-and-on
high voltage

connecting error in tester
bad act of the main switch
 poor contact of CDI joint
 short circuit or poor contact of CDI
ground wire
bad act of charge coil（peak voltage
test）
bad act of trigger （peak voltage test）.
 bad act of connector for high voltage
wire
bad act of CDI group（when item- is
abnormal or when there is no spark in the
sparkplug）
side
voltage
Normal high voltage, no spark

bad act of spark plug or power leak in
secondary coil
bad act of ignition coil
no high voltage

The interior resistance is too low and
test it with a designated tester.
The cranking speed is too low.

The tester is disturbed（if the voltage
measured for several times is above
standard, then the value is normal）.
bad act of the charge coil （ no
abnormality in Item -）
charge
coil
no high voltage ， off-and-on
high voltage

bad act of the ignition coil

bad act of the charge coil
high voltage too low

The interior resistance is too low and
test it with a designated tester.
The cranking speed is too low.

The tester is disturbed（if the voltage
measured for several times is above
standard, then the value is normal）.
bad act of the charge coil （ no
abnormality in Item -）
trigger
no high voltage ， off-and-on
high voltage

bad act of the ignition coil

bad act of the trigger
