The display resolution is 0.1 mm.
Principle: Phase measurement
Type: Coaxial, visible red laser
Carrier wave: 658 nm
Measuring system: System analyser basis 100 MHz - 150 MHz
8.3 Distance Measurement without Reflectors
A5
Kodak Gray Card Range D Range E Range F
[m] [ft] [m] [ft] [m] [ft]
White side, 90 % reflec-
tive
250 820 400 1310 >500 >1640
Grey side, 18 % reflec-
tive
150 490 200 660 >200 >660
A10
Kodak Gray Card Range D Range E Range F
[m] [ft] [m] [ft] [m] [ft]
White side, 90 % reflec-
tive
800 2630 1000 3280 >1000 >3280
Grey side, 18 % reflec-
tive
400 1320 500 1640 >500 >1640
Range of Measurement: 1.5 m - 1200 m
Display unambiguous: up to 1200 m
Range Description
D Object in strong sunlight, severe heat shimmer
E Object in shade, or overcast
F Underground, night and twilight
Standard
measuring
Standard deviation
ISO 17123-4
Measure time, typi-
cal [s]
Measure time, maxi-
mum [s]
0 m - 500 m 2 mm + 2 ppm 3 - 6 12
>500 m 4 mm + 2 ppm 3 - 6 12
Object in shade, sky overcast. Beam interruptions, severe heat shimmer and moving objects
within the beam path can result in deviations of the specified accuracy. The display resolution is
0.1 mm.
Type Description
Type Coaxial, visible red laser
Characteristics
Range
Atmospheric conditions
Accuracy
Characteristics
Technical Data 53
