Humidity
Type Protection
All instruments Max 95 % non condensing
The effects of condensation are to be effectively
counteracted by periodically drying out the instru-
ment.
Type Additive Constant [mm] AiM Scout
Standard prism, ZPR100 0 yes yes
Mini prism, ZMP100 0 yes yes
Mini prism, ZMP101 +17.5 yes yes
360° prism,
ZPR1 / GRZ122
+23.1 yes yes
360° Mini prism, GRZ101 +30.0 yes not recommended
Reflector tape S, M, L +34.4 yes no
Reflectorless +34.4 no no
There are no special prisms required for AiM or for Scout.
Description Value
Working range 5 m to 150 m (15 ft to 500 ft)
Position accuracy 5 cm at 100 m (1.97" at 330 ft)
The following automatic corrections are made:
•
Line of sight error
•
Vertical index error
•
Tilting axis error
•
Standing axis tilt
•
Earth curvature
•
Refraction
•
Circle eccentricity
•
AiM zero point error
•
Compensator index error
8.9 Scale Correction
By entering a scale correction, reductions proportional to distance can be taken into account.
•
Atmospheric correction.
•
Reduction to mean sea level.
•
Projection distortion.
The slope distance displayed is correct if the scale correction in ppm, mm/km, which has been
entered corresponds to the atmospheric conditions prevailing at the time of the measurement.
The atmospheric correction includes:
•
Adjustments for air pressure
•
Air temperature
•
Relative humidity
For highest precision distance measurements, the atmospheric correction should be determined
with an accuracy of 1 ppm. The following parameters must be redetermined:
Reflectors
Navigation Light
(NavLight)
Automatic corrections
Use of scale correction
Atmospheric correction
DD1
Technical Data 61
