8.3 Overview

2 3 4

Figure 8-1

No. Name Description

1 Memory Card Slot

Receives a micro SD card (SD/SDHC,

version 2.0 only, Class 10).

2 Zoom Screw Holds the zoom lens in place.

3 Focus Screw Holds the focus lens in place

4 Default Button

Resets all configurations to factory default.

See 22.3. Restoring to Factory Default

Settings.

Default Chapter12
