15.1 Packing List

15.1.1 Packing List for Hard-Ceiling Mount

• Fixed IP Dome

• Torx Wrench

• Mounting Plate

• Short Screw Anchor x 3

• Ceiling Screw x 3

• Plate Screw x 3

• TV-out Wire

• Sticker

• GV-IPCAM H.264 Software

• GV-IPCAM H.264 Quick Start

Guide

• GV-NVR Software DVD • GV-NVR Quick Start Guide

Note: Power adapter can be purchased upon request.
