GeoVision GV-FD120D User Manual

15.4.2 In-Ceiling Mount
Figure 15-10
1. Follow step 2 in the 15.4.1 Hard-Ceiling Mount to remove the housing
cover and take out the camera body.
2. Paste the supplied sticker onto a desired location on the ceiling and
cut a circle on the ceiling along the edge of the sticker.
3. On the mounting plate, locate the 3 holes labeled as 1 and insert the
3 copper pillars from the back side.
Figure 15-11
214
