Cube Camera

16.4 Installation

Follow the steps below to install, connect to and adjust your Cube Camera

and Wireless Cube Camera.

1. Put the supporting rack on the desired location and make marks for

screw anchors.

Figure 16-2

2. Drill the marks and insert the screw anchors.

3. Secure the supporting rack onto the wall using the supplied screws.

4. Screw the camera onto the supporting rack and fasten the indicated

screw.

Figure 16-3

227
