518
GV-EFD1100-0F
93°
Horizontal
FOV
GV-EFD1100-1F
64°
Operation (Focus / Zoom / Iris)
Fixed
IR LED Quantity
12 IR LEDs
Max. IR Distance
15 m (50 ft)
Operation
Video Compression
H.264, MJPEG
Video Stream
Dual streams from H.264 or MJPEG
Frame Rate 30 fps at 1280 x 1024
Image Setting
Brightness, Contrast, Saturation, Sharpness,
Gamma, White Balance, Flicker-less, Image
Orientation, Shutter Speed, D/N Sensitivity,
Backlight Compensation, WDR, Defog
Audio Compression
G.711, AAC (Optional)
Audio Support
One-Way Audio
Note: The frame rate and performance may vary depending on the number
of connections and data bitrates (different scenes).
Video Resolution
4:3
1280 x 960, 640 x 480, 320 x 240
16:9
1280 x 720, 640 x 360, 448 x 252
Main Stream
5:4
1280 x 1024, 640 x 512, 320 x 256
4:3
640 x 480, 320 x 240
16:9
640 x 360, 448 x 252
Sub Stream
5:4
640 x 512, 320 x 256
To Next Page
