3. Technical data
Tool type PH 1 PH 2 PH 2-VK PH-Axial VAS (PH1,
PH2)*
Weight (kg) 1.2 1.3 1.3 1.8 0.43
Operating pressure (bar) 5-7 5-7 5-7 5-7 4-6
Hose connection (Ø mm) ¼“ 6 6 6 6 -
Spent mandrel container capacity 40-80 40-80 20-40 50-100 50-100
Air consumption (Nl/rivet) 0.8-1.2 1.2-1.8 1.2-1.8 1.2-1.8 1.2
Compressed air quality (ltered)
    
Setting force (N) at 5 bar 5200 7375 5200 7375 -
Stroke (mm) 15 15 14 15 -
Hydraulic oil (ml)
Renolin Eterna 32
25 25 25 30 -
Noise emission L
pa
(dB)
Measurement uncertainty k = 3 dB
83 83 83 82.5 84.5
Vibration (m/s²)
(measurement uncertainty
k = 1.5 m/s²)
<2.5 <2.5 <2.5 <2.5 -
Integrated spent mandrel
evacuation
- -
 
-
* Only available as spare part
