6. Nosepiece assignment
Rivet Ø Rivet material PH 1 Part No. PH 2 Part No.
2.4 Aluminium 16/18
143 4285 10/18* 143 4055
3.2
CAP
®
Al, CAP
®
Cu
16/18
143 4285 10/18* 143 4055
3 and 3.2
Al, Cu, steel, stainless steel, Stinox,
Al, PG Al, PG steel
16/24
143 4288 10/24* 143 4061
4
Al, Cu, CAP
®
Al, CAP
®
Cu
16/24
143 4288 16/24 143 4285
4 PG Al, steel, Al 16/27
143 4289 16/27 143 4288
4 Stainless steel, Stinox, PG steel 16/29
143 4290 16/29 143 4289
4.8 and 5
Al, CAP
®
Al, CAP
®
Cu, PG Al
-
16/29 143 4290
4.8 and 5 Steel, Al -
16/32 143 4291
4.8 and 5 Stainless steel, Stinox, PG steel -
16/36 143 4292
* Small jaw assembly required
• PH 1/PH 2 (Part No. 145 6783)
• PH-Axial (Part No. 145 8075)
Rivet Ø Rivet material PH
2-VK
Part No. PH-Axial Part No.
2.4 Aluminium 10/18
143 4055 10/18* 143 4055
3.2
CAP
®
Al, CAP
®
Cu
10/18
143 4055 10/18* 143 4055
3 and 3.2
Al, Cu, steel, stainless steel, Stinox,
Al, PG Al, PG steel
10/24
143 4061 10/24* 143 4061
4
Al, Cu, CAP
®
Al, CAP
®
Cu
10/24
143 4061 16/24 143 4285
4 PG Al, steel, Al 10/27
143 4062 16/27 143 4288
4 Stainless steel, Stinox, PG steel -
16/29 143 4289
4.8 and 5
Al, CAP
®
Al, CAP
®
Cu, PG Al
-
16/29 143 4290
4.8 and 5 Steel, Al -
16/32 143 4291
4.8 and 5 Stainless steel, Stinox, PG steel -
-
