2.2.2 Control buttons
The keys are used to navigate through the machine program and
to select functions.
Function Key Description
Open the door The machine door unlocks and
opens.
More Can be selected during a
process.
Navigation The Up, Down, Right, and Left
arrows are used to control the
cursor and other values in the
process diagram, also called
cursor keys.
In operating mode is used
as the START key and to
acknowledge the alarm to stop
the audible signal.
When navigating, the
machine’s program is used
to select, enter, or confirm the
highlighted alternatives.
Back Return to the previous window
or menu, or undo an entry.
Menu Go to main menu.
2.2.3 Window
Information is displayed in the window about the current process
(process window) and a number of various types of ”pop-up”
windows (Alarm window, Information windows, Dialog window and
Input window).
2.2.3.1 Example of a Process window
TEMP CHAMBER
TEMP IND CHAMBER
91.2 °C 91.2 °C
000567
The process window displays the current process and the
remaining time. See also in the 3.1.3 Process screen section.
2 PRESENTATION
14 (128) TECHNICAL MANUAL GETINGE WD15 CLARO
<Doc_TEC><Doc_6001396902><Rev.I><Lang_en>
