Getinge WD15 CLARO Technical Manual

Error
code
Error Note
A30 High temperature in
wash chamber
The temperature in the chamber is more than 5°C above the
highest reference point.
A31 External communication
error
DS30 Netcom is selected and communication with Netcom is
not
working. (If SF215 is set.)
Possible action:
a. Check the cabling.
b. Check the settings
A32 Log error DS30 Netcom is selected and the log is not working. (If SF217
and
SF218 are not set 2 min. after end of process.)
Possible action:
a. Check the USB memory stick
b. Check the settings
A33 Low disinfection
temperature
The temperature in the wash chamber is below the set value
for disinfection
(for a period longer than 60 seconds).
Possible action:
a. Check that there is power on all phases up to the
elements.
b. Check the calibration of the temperature sensors
4 ALARM MANAGEMENT
TECHNICAL MANUAL GETINGE WD15 CLARO 59 (128)
<Doc_TEC><Doc_6001396902><Rev.I><Lang_en>

Getinge WD15 CLARO Specifications

General

Type	Washer-disinfector
Cleaning Performance	Complies with EN ISO 15883
Power Supply	230V, 50/60Hz
Washing levels	2 levels
Temperature Range	Up to 93°C
Programs	Multiple programmable cycles
Water Consumption	Approx. 15 L per cycle
Control System	Microprocessor-controlled with touch panel
Application	Cleaning and disinfection of laboratory glassware and utensils
